Atmospheric Rivers...A New Scale

Unlike the Gulf and East Coasts of the United States, the West Coast is not in a favorable area to take a direct hit from a hurricane. Although those living in the western U.S. can receive heavy rain from the remnants from a tropical cyclone, the far more common harbingers of flooding rain across the West are atmospheric rivers (ARs). ARs are long corridors or streams of enhanced water vapor content in the atmosphere that transport moisture from the tropics to higher latitudes. One famous example of an atmospheric river is the “Pineapple Express.” As seen in the provided satellite image, the Pineapple Express connects locations along the West Coast with enhanced atmospheric moisture from near Hawaii.

Not all AR events across the West are destructive, though. Some, if they bring their rain down at a more moderate rate, can even be beneficial in alleviating drought conditions. Recently, scientists, including F. Martin Ralph with the Center for Western Weather and Water Extremes, as well as Jonathan J. Rutz of the National Weather Service, devised a scale to categorize ARs that are both beneficial and destructive. Their scale, like the Saffir-Simpson scale for hurricanes, ranks ARs on a scale from 1 (Primarily beneficial) to 5 (Primarily hazardous). However, the rankings on this scale are not based on wind destruction, but instead on two factors: the amount of water vapor being transported by the atmosphere, and the duration those conditions last at any one point. When an AR lasts less than 24 hours at a location, it is demoted one category, but if it lasts longer than 48 hours, it gets promoted one category.

The new Atmospheric River Category Scale looks to provide both forecasters and the general public a way to better differentiate between beneficial, drought-busting AR events and their more hazardous counterparts. For future AR events, the predicted ranking of the storm will be communicated both on the Center for Western Weather and Water Extremes website, as well as their Twitter account

Atmospheric River Pineapple Express Satellite
Satellite image of an AR known as the "Pineapple Express" Feb. 17, 2017 - [CIMSS]
Atmospheric River Category Scale
Atmospheric River Category Scale - [F. Martin Ralph et al, 2019]
